El robot Turin TR70-2110B, perteneciente a la gama industrial de seis ejes, combina una capacidad de carga de 70 kg con un alcance de 2.110 mm. Ideal para manipulación de materiales, ensamblajes pesados y paletizado, destaca por su potencia, estabilidad y precisión en procesos de automatización avanzada.
TR70-2110B
Categoría: Welding Robot SeriesModelo: TR10-1450B/ARCCarga útil: 10 KgAlcance: 1455 mm
| TR70-2110B | |||
| Rated Payload | 70kg | ||
| Arm Reach | 2119mm | ||
| Position Repeatability | ±0.08mm | ||
| Protection Level | IP54 | ||
| Structural Form | Vertical Multi-jointed Series Structure | ||
| DOF | 6 | ||
| Max Speed | J1 | 127°/s | |
| J2 | 105°/s | ||
| J3 | 165°/s | ||
| J4 | 253°/s | ||
| J5 | 250°/s | ||
| J6 | 372°/s | ||
| Max Operation Area | J1 | ±170° | |
| J2 | -90°~135° | ||
| J3 | -185°~90° | ||
| J4 | ±200° | ||
| J5 | ±105° | ||
| J6 | ±360° | ||
| Wrist Allowable Torque | J4 |
330Nm |
|
| J5 | 330Nm | ||
| J6 | 165Nm | ||
| Maximum Allowable Inertia of the Wrist | J4 | 30kgm² | |
| J5 | 30kgm² | ||
| J6 | 16.8kgm² | ||
| Rated Power | 6.8kw | ||
| User Wiring | RVV10*0.2 | ||
| User Piping | 2*Φ8mm | ||
| User Distribution | three phase AC380V-10%~+10% | ||
| Applicable Environment | Temperature | 0~45°C | |
| Humidity | 10%~80%RH | ||
| Max Temperature Gradient | 1.5°C/min | ||
| Body Weight |
600kg |
||
| Control Cabinet | TRC3-C06 | ||
| Installation Method | Floor-standing | ||
