El robot Turin TR10-1000S/TH, de la serie SCARA, ofrece una carga útil de 10 kg y un alcance configurable de 800/900/1000 mm. Con una repetibilidad de ±0,02 mm (J1/J2) y ±0,01 mm (J3), esta solución es ideal para tareas de soldadura ligera, estampación, manipulación rápida y automatización de precisión en líneas industriales.
TR10-1000S/TH
Categoría: Scara RobotModelo: TR10-1000S/THCarga útil: 10 KgAlcance: 800-900-1000 mm
| TR10-1000S/TH | |||
| Payload | Rated | 10kg | |
| Max | – | ||
| Arm Reach | 1st + 2nd Robotic Arm | 800/900/1000mm | |
| 1st Robotic Arm | 400/500/600mm | ||
| 2nd Robotic Arm | 400mm | ||
| Position Repeatability | J1/J2 | ±0.02mm | |
| J3 | ±0.01mm | ||
| J4 | ±0.01° | ||
| Protection Level | IP40 | ||
| Max Speed | J1/J2 | 11304/12089/12874mm/s | |
| J3 | 1000mm/s | ||
| J4 | 720°/s | ||
| Max Operation Area | J1 | ±136° | |
| J2 | ±145° | ||
| J3 | 200mm | ||
| J4 | ±360° | ||
| Allowable Moment of Inertia of R Axis | Rated |
0.02kg·m² |
|
| Max | 0.3kg·m² | ||
| Pressing Force of J3 | 200N | ||
| Noise Level | Laeq≤85dB(A) | ||
| Takt Time | 0.6s | ||
| Rated Power | 1.35kw | ||
| User Wiring | RVV10*0.2 | ||
| User Piping | 3*Φ6mm | ||
| User Distribution | single-phase AC220V-10%~+10% | ||
| Applicable Environment | Temperature | 0~45°C | |
| Humidity | 10%~80%RH | ||
| Body Weight |
46/48/50kg |
||
| Control Cabinet | TRC4-A03 | ||
| Mounting Holes | 198*195mm(4-Φ14mm) | ||
| Installation Method | Countertop Installation | ||
Descargar catálogo
